OWPIRODLO

• Sensor uses Passive Infrared technology.
• OWPIROD models can be manually overridden with built-in override function.
• OWPIRODLO models can be overridden with separate override switches.
• 110° detection up to 18 metres • Suitable for installing on walls and ceiling both interior and exterior.
• Fits standard mounting blocks using 84mm centres (example: HYSMB2025).
• 3 wire design (Active, Neutral, Sensor load) for greater reliability.
• Relay in circuit allows for loads up to 2400W (incandescent).
• Easy mounting and adjustment.
• Easy sensing, light level and on time adjustment.
• LED compatible • IP66 Rating.
• Minimum load <10W.
• Must be installed by a licenced electrician.

Discover more, view Data Sheet in Downloads or watch Trader’s KNOW YOUR PRODUCT VIDEOS here.
