Buffalo DIN Rail Accessory Mounting Enclosures provide a facility to mount up to 4 poles of equipment such as MCB’s and RCDs - external to a switchboard in an environment needing a high level of protection.
As with all Buffalo products, they are manufactured from robust, UV and good chemical resistant material to provide long reliable life in the dust and wet.
The BU4DINLED features a 250V~ LED inbuilt into the cover, which has long cables with crimped ends to allow it to be wired for power available into the module - or outgoing power available - depending on the application.
Cable length is suitable for wiring below the DIN rail and can reach easily into the lower section of switch gear installed into the enclosure.
Chemical Resistant Orange for Acid Applications
Installer Tip: Fix cover screws to maximum torque levels of 0.6Nm.
Discover more, view Data Sheet in Downloads or watch Trader’s KNOW YOUR PRODUCT VIDEOS here.
